SMK Solar Battery Charge Regulators
SMK MPPT 30 amp Solar Charge Controller
For the medium-size solar systems up to 30 amps input. Automatically detects correct battery voltage, and gives the ability to monitor the system remotely, using RS485 port.
SMK MPPT Solar charge controller is an advanced maximum power point tracking (MPPT) battery charger for off grid photovoltaic systems.
Why choose this 30 amp controller?
- At least 30% higher solar harvest for power than PWM controllers
- Wider range of Solar PV voltage input 18 v – 100 v DC
- LCD and LED displays the output every second
- Large heat sink for excellent cooling, will not de-rate output
- Economical and non-corroding plastic casing
- Battery type and voltage can be easily set using the LCD screen.
Features：
- 12V/24V/46V/48V Battery auto detect, parallel design
- Multi-stage charging optimizes battery performance
- MPPT eficiency >99.5%, Peak conversion efficiency 97.5%
- Compatible with Gel. AGM. Flooded. Sealed lead acid and Lithium batteries
- Comprehensive protection
- Dual fan cooling design
- Easy installation and commissioning
- Monitor solar output online via RS485 communition, Ethernet/RS232 communication Optional
| Model | SCH-20A-EL | SMK-SCH-30A-EL |
| Solar System Voltage | 12V/24V Auto work | |
| Electrical | ||
| PV Operating Voltage | 18～100Vdc@12V 35～100Vdc@24V | |
| Max. PV input power | 12V 300W | 12V 400W |
| 24V 600W | 24V 800W | |
| Rated input current | 20A | 30A |
| Rated DC load current | 30A | |
| Self consumption | 2W | |
| Max. Efficiency |
97.5% |
|
| Protection | PV array short circuit, over charging,battery reverse polarity,output short circuit | |
| Suits Battery Types | Sealed Gel, AGM, Flooded, Lithium Battery | |
| Charge algorithm | 3 stage charging: Bulk, Absorption, Float charging | |
| Bulk charge voltage | Sealed: 14.4V AGM 14.2V Gel:14.2V Flooded:14.6V User defined:10-15V | |
| Float charge voltage | Sealed/Gel/AGM:13.8V Flooded:13.7V User defined:10-15V | |
| Equalize charge voltage | Sealed 14.6 v, AGM:14.8 v, Flooded:14.9 v | |
| Load disconnect volts | 10.5V ～12V Adjustable | |
| Low voltage reconnect | 12.5V | |
| Temp compensation | 5mV/℃/2V with BTS | |
| Net weight | 1.4 kg | 1.6 kg |
| Gross weight | 1.8 kg | 1.9 kg |
| Dimension | 150 x 160 x 80 mm | 170 x 160 x 180 mm |
| Cooling | Heat sink cooling | |
| Enclosure | IP21 | |
| Operating temperature | -25℃～60℃ | |
| Storage Temperature | -40℃～80℃ | |
| Humidity | 100% non-condensing | |
| Warranty | Two years | |
Price: $145
SCH MPPT 80 amp Solar Charge Controller
Reliable MPPT controller for inputs up to 80 amps, with auto detect voltage 12 to 48 v, and maximum input voltage of 150 volts.
Why choose this 30 amp controller?
- At least 30% higher solar harvest for power than PWM controllers
- Wider range of Solar PV voltage input 18 v – 100 v DC
- LCD and LED displays the output every second
- Large heat sink for excellent cooling, will not de-rate output
- Economical and non-corroding plastic casing
- Battery type and voltage can be easily set using the LCD screen.
Features：
- 12V/24V/46V/48V Battery auto detect, parallel design
- Multi-stage charging optimizes battery performance
- MPPT eficiency >99.5%, Peak conversion efficiency 97.5%
- Compatible with Gel. AGM. Flooded. Sealed lead acid and Lithium batteries
- Comprehensive protection
- Dual fan cooling design
- Easy installation and commissioning
- Monitor solar output online via RS485 communition, Ethernet/RS232 communication Optional
Specifications:
| Model | SCH-80A |
|---|---|
| Solar System Voltage | 12V/24V/36V/48V Auto work |
| Electrical | |
| PV Operating Voltage | 18~150Vdc@12V 35~150Vdc@24V 50~150Vdc@36V 60~150Vdc@48V |
| 12V 1000W | |
| 24V 2000W | |
| Max. PV input power | 36V 3000W |
| 48V 4000W | |
| Rated Output Current | 80A Adjustable(0A~80A) |
| Rated DC load Current | 60A |
| Self consumption | 2W |
| Max.Conversion Efficiency | 98.5% |
| Protection | PV array short circuit, over charging,battery reverse polarity,output short circuit |
| Battery charging | |
| Battery Type | Sealed Gel AGM Flooded Lithium Battery User define |
| Charge algorithm | 4 stage: Bulk, Absorption, Float, Equalize charging |
| Bulk charge voltage | Sealed: 14.4V AGM 14.2V Gel:14.2V Flooded:14.6V User defined:10-15V |
| Float charge voltage | Sealed/Gel/AGM:13.8V Flooded:13.7V User defined:10-15V |
| Equalize charge voltage | Sealed 14.6V AGM:14.8V Flooded:14.9V |
| Load disconnect voltage | 10.5V ~12V Adjustable |
| Low voltage reconnect voltage | 12.5V |
| Temperature compensation | 5MV/°C/2V with BTS |
| Communication | |
| Communication Port | RS485 |
| Physical | |
| Net weight | 7.8kg |
| Gross weight | 8.7kg |
| Cooling | Heatsink cooling |
| Enclosure | IP54 |
| Environment | |
| Ambient operating temperature | -25°C~60°C |
| Storage Temperature | -40°C~80°C |
| Humidity | 100% non-condensing |
Price: $850
